Specification |
Unit |
WHP-300 |
|
Punch Force |
t |
30 |
|
Max. Processing Size(with One Reposition) |
mm |
1250×2500 |
1250×5000 |
Feeding Speed |
m/min |
X:80 Y:60 |
X:80 Y:60 |
No. of Station |
no. |
32 |
32 |
No. of Auto-index |
no. |
2 |
2 |
No. of Controlling Axis |
no. |
4 |
4 |
Processing Thickness |
mm |
6.35 |
6.35 |
Max. Nibbling Speed |
hpm |
1650 |
1650 |
Max. Punch Hit |
hpm |
600 |
600 |
Punch Hit At 25mm Pace |
hpm |
X:450 Y:350 |
X:400 Y:280 |
Max. punch Diameter Per Time |
mm |
Φ88.9 |
Φ88.9 |
Main Motor Power |
KW |
11 |
11 |
Hole Accuracy |
mm |
±0.10 |
±0.10 |
Cnc System |
|
BECKHOFF |
BECKHOFF |
Turret Rotate |
rpm |
30 |
30 |
Outline Dimension |
mm |
5020×2680×2340 |
5020×5000×2340 |
Machine Structure |
|
Streamline O-Type |
Streamline O-Type |
Note:All of models mentioned above can be designed into the table with 4000mmm.
