34-100 |
34-160 |
34-200 |
34-250 |
34-315 |
34-400 |
34-400A |
34-500 |
||
|
Capacity |
kN |
1000 |
1600 |
2000 |
2500 |
3150 |
4000 |
2000+1000×2 |
5000 |
|
|
Return Force |
kN |
160 |
210 |
240 |
400 |
600 |
500 |
240+165×2 |
900 |
|
|
Slide Stroke |
mm |
510 |
560 |
710 |
710 |
800 |
800 |
800 |
900 |
|
|
Shut Height |
mm |
800 |
900 |
1120 |
1120 |
1200 |
1200 |
1200 |
1400 |
|
|
Hyd. Pad Capacity |
kN |
400 |
630 |
630 |
1000 |
1250 |
1250 |
1250 |
2000 |
|
|
Hyd. Pad Return Force |
kN |
147 |
250 |
250 |
320 |
360 |
360 |
360 |
780 |
|
|
Hyd. Pad Stroke |
mm |
200 |
200 |
250 |
250 |
300 |
300 |
300 |
350 |
|
|
Slide Speed |
Idle Stroke |
mm/s |
150 |
160 |
200 |
220 |
140 |
180 |
180 |
150 |
|
Pressing |
mm/s |
11~22 |
7~16 |
8~19 |
9~20 |
8~19 |
9~20 |
9~20 |
10~22 |
|
|
Return |
mm/s |
130 |
100 |
140 |
120 |
90 |
160 |
130 |
120 |
|
|
Hyd. Pad Speed |
Eject |
mm/s |
55 |
40 |
60 |
50 |
45 |
60 |
60 |
55 |
|
Return |
mm/s |
160 |
105 |
150 |
155 |
165 |
220 |
220 |
140 |
|
|
Bolster |
LR |
mm |
690 |
1000 |
1200 |
1200 |
1500 |
1750 |
2000 |
2200 |
|
FB |
mm |
630 |
800 |
1000 |
1000 |
1200 |
1250 |
1500 |
1600 |
|
|
Hydraulic Pad |
LR |
mm |
350 |
650 |
950 |
950 |
1120 |
1270 |
1420 |
1720 |
|
FB |
mm |
350 |
650 |
800 |
800 |
820 |
820 |
1120 |
1120 |
|
|
Outline Size |
LR |
mm |
2880 |
2980 |
3280 |
3380 |
3900 |
4250 |
4500 |
4700 |
|
FB |
mm |
1650 |
1770 |
2000 |
2100 |
2500 |
2750 |
300 |
3100 |
|
|
Above Floor |
mm |
3250 |
3350 |
3900 |
4300 |
5200 |
5350 |
5600 |
5800 |
|
|
Main Motor Power |
kW |
15 |
15 |
22 |
30 |
37 |
2×22 |
2×22 |
2×30 |
|
|
Weight |
kg |
7000 |
10300 |
13000 |
16200 |
25000 |
31000 |
40000 |
57000 |
|
|
|
34-500A |
34-630 |
34-630A |
34-800 |
34-800A |
34-800B |
34-1000 |
||
|
Capacity |
kN |
2500+1250×2 |
3150×2 |
3150+1600×2 |
8000 |
4000+2000×2 |
4000+2000×2 |
10000 |
|
|
Return Force |
kN |
400+277×2 |
450×2 |
450+210×2 |
1000 |
500+240×2 |
500×2 |
1350 |
|
|
Slide Stroke |
mm |
1000 |
900 |
1200 |
1000 |
1300 |
1300 |
1000 |
|
|
Shut Height |
mm |
1400 |
1500 |
1600 |
1800 |
1800 |
1800 |
1800 |
|
|
Hyd. Pad Capacity |
kN |
1000×2 |
1250×2 |
1000×2 |
1600×2 |
1600×2 |
1000+500×4 |
2000×2 |
|
|
Hyd. Pad Return Force |
kN |
320×2 |
360×2 |
320×2 |
600×2 |
600×2 |
450 |
580×2 |
|
|
Hyd. Pad Stroke |
mm |
350 |
350 |
400 |
400 |
400 |
400 |
400 |
|
|
Slide Speed |
Idle Stroke |
mm/s |
170 |
150 |
160 |
150 |
200 |
200 |
160 |
|
Pressing |
mm/s |
10~19 |
8~19 |
8~19 |
8~18 |
8~18 |
8~18 |
8~19 |
|
|
Return |
mm/s |
100 |
130 |
130 |
140 |
140 |
140 |
140 |
|
|
Hyd. Pad Speed |
Eject |
mm/s |
55 |
45 |
60 |
45 |
45 |
95 |
45 |
|
Return |
mm/s |
170 |
165 |
185 |
125 |
125 |
150 |
155 |
|
|
Bolster |
LR |
mm |
3000 |
2500 |
3500 |
2200 |
3500 |
4000 |
2500 |
|
FB |
mm |
2000 |
1800 |
2000 |
